What Are The Requirements For The Lid Configuration Of The Vacuum Emulsifier
The vacuum emulsifier is a kind of emulsifier, and its special feature is that the working principle of the emulsifier is to shear, disperse and impact the material through the high-speed rotation of the homogenizing head connected to the engine. Through operation, the material will become delicate and harmonious. The vacuum emulsifier completes a series of operations in a vacuum. We introduce the characteristics of the vacuum emulsifier to you.
1. The fully enclosed vacuum system meets the sanitary conditions and has no bacteria requirements.
2. The vacuum homogenizing emulsifier, agitator and high shear emulsifier of the concentric double-axis structure can be operated independently, and the emulsification effect on the material is very good.
3. High Shear Emulsifier is mainly used for high-viscosity materials, especially paste materials, and the wall scraper is installed on the agitator.
4. The main tank of the vacuum homogenizing emulsifier can be turned over at will, which is very convenient for unloading, maintenance and cleaning.
5. The electrical control part of the vacuum emulsifier adopts imported products to ensure the stability and reliability of the control.
It complies with GMP specifications and can be configured with CIP and SIP systems.
It is a comprehensive multifunctional non-standard mixing equipment. Its integration is not only reflected in meeting the production needs of various emulsification processes, but also in the integration of equipment configuration and design. Take the lid of our vacuum emulsifier as an example.
The lid of the vacuum emulsifier is configured according to the emulsification process. These configurations greatly promote and optimize the operation of the emulsification process. Configurations include:
1. Observation port: also known as a window mirror, through which the emulsification tank can be observed. In order to avoid steam blurring the glass lens, a special design of a rotatable scraper is used to scrape off the water vapor and better observe the emulsification tank;
2. Small feed port: trace elements can be added during the emulsification process;
3. Compressed air inlet: customer discharge, positive pressure enters compressed air, and discharge is convenient and smooth;
4. Air filter: used to filter air and reduce the pollution of materials by external air;
5. LED lighting: Italian window rearview mirror Optimize the selection of LED lights for lighting, which is more user-friendly, longer-lasting and durable;
6. Vacuum port: used for vacuuming and exhausting;
7. Vacuum pressure gauge: in negative vacuum and positive pressure intake, the vacuum degree can be observed by the pressure gauge displaying the pressure value;
8. Cleaning spray ball 3: CIP cleaning, which greatly optimizes the cleaning process;
9. Feed port with filter: can filter the feed to ensure the consistency and cleanliness of the material;
10. The inlet is equipped with a guide tube: so that the material can be fed from the tank wall according to the specified path.
Do you think the configuration requirements of the vacuum emulsifier cover are high now?
