Very Useful And Thoughtful Configuration On The Vacuum Emulsifier

Publish Time: Author: Site Editor Visit: 26

The pot cover of High Shear Emulsifier is configured according to the emulsification process. These configurations greatly facilitate and optimize the operation of the emulsification process. The configurations include:

1. Observation port: also called window mirror, through which the situation in the emulsification pot of the vacuum emulsifier can be observed. In order to avoid the steam blurring the glass lens, a rotatable scraper is specially designed to scrape off the water vapor and better observe the situation in the emulsification pot;

2. Small material feed port: trace elements can be added during the emulsification process;

3. Compressed air inlet: when the customer discharges the material, compressed air is positively pressed in, which is convenient and smooth for discharge;

4. Air filter: used to filter air , reduce the pollution of materials by external air;

5. LED lighting: The window mirror has been optimized and LED lighting is selected for lighting, which is more user-friendly, longer life and durable;

6. Vacuum port: used for vacuuming and exhausting;

7. Vacuum pressure gauge: During negative pressure vacuuming and positive pressure air intake, the vacuum degree can be observed by the pressure value displayed by the pressure gauge;

8. 3 cleaning spray balls: used for CIP cleaning, which greatly optimizes the cleaning process;

9. The feed port is equipped with a filter: the feed can be filtered to ensure the consistency and cleanliness of the material;

10. The feed port is equipped with a guide pipe: the material can be fed from the pot wall according to the specified path.
